Product Number | 03OP002 | 50521 |
Rated voltage + frequency | 230 V / 50 Hz |
UVC power consumption – W | 12 W |
Pump power consumption – W | 40 W |
UVC power cable length – m | 3 m |
Pump power cable length – m | 10 m |
Net weight | 7.700 kg |
Guarantee - years | 2 Years |
UVC power – W | 9 W |
Number of blue filter foams – pc. | 2 Units |
Number of black filter foams – pc. | 1 Units |
Number of bio-surface elements – pc. | 20 Units |
Pollutant level indicator | Yes |
Temperature display | No |
Connection inlet - mm | 25 / 32 / 38 mm |
Connection inlet | 1", 1 ¼", 1 ½" |
Connections outlet - mm | 25 / 32 / 38 mm |
Connections outlet | 1", 1 ¼", 1 ½" |
Max. operating pressure – bar | 0.2 bar |
Suitable for ponds up to max. – m³ | 6 m³ |
Suitable for ponds with fish stock – m³ | 3 m³ |
Suitable for ponds with koi – m³ | 1.5 m³ |
Part Name | Part Number |
Foam Set | 15564 | 03OP011 |
O-Ring x 7 | 28812 | 11OS103 |
ASM clamp | 47828 | 11OS333 |
Filter Lid | 35815 | 11OS227 |
Additional pack | 15313 | 11OS117 |
Electrics | 15665 | 11OS038 |
9w UV Globe (240v) | 11PS165 |
Clip bolt set | 15535 | 11OS108 |
Quartz Sleeve | 13312 | 11OS049 |
Pump | 13745 | 11OS048 |
ASM Pump Housing | 35770 | 11OS313 |
Impeller | 18013 | 11OS079 |
