Product Number | 02OD029 | 42791 |
Rated voltage + frequency | 220 - 240 V / 50 Hz |
Power consumption - W | 270 W |
Power cable length - m | 10 m |
Net weight | 5.500 kg |
Guarantee (+ request guarantee) - years | 3 + 2 Years |
Max. flow rate per minute | 200 l/min |
Max. flow rate - l/h | 12000 l/h |
Max. head height, metres | 7 m |
Connection pressure-side - mm | 38 mm |
Connection pressure-side | 1 ½" |
Connection sunctions-side - mm | 38 mm |
Connection sunctions-side | 1 ½" |
Connection for hoses - mm | 25 / 32 / 38 mm |
Hose connection | 1", 1 ¼", 1 ½" |
Filter intake surface | 220 cm² |
Electronic adjustment | Yes |
Setup type | Can be set up underwater & dry installed |
Part Name | Part Number |
Anti-freeze housing | 34961 | 11OS226 |
Anti-Freezing Foam | 26003 | 11OS290 |
Pre Filter | 35252 | 11OS258 |
O-Ring | 3594 | 11OS289 |
Suction Unit | 26405 | 11OS278 |
Impeller | 25180 | 11OS296 |
Int. Housing | 11870 | 11OS060 |
Pump Housing | 35244 |
11OS059 |
